MB542-180型全自動對折卷板機(MB542-180 Automatic Fabric Doubling & Winding Machine)
發布時間：2014-07-04
用途 Purpose
本機專供平幅布匹對折為雙幅后板卷而設計,布匹可由散狀或卷圓狀上布,備有兩套自動對邊裝置,使對折卷取后的布邊整齊一致,又裝有自動退布裝置,卷取完后的布卷可以自動脫落,不必人力拉出,操作方便、省時、省力，自動化程度高。
本機亦可套裝雙幅圓卷裝置，針織布，彈性布料可另行設計。
This machine is designed to fold woven fabric to half width and roll it up flat roll. Fabric can be processed from both rolled or lapped form equipped with two sets of automatic edge control device to control fabric edge. Auto take-up device can release finished rolls automatically from machine, no manual work is required and very easy to operate.
Round-shape rolling device can installed to roll fabric in round roll provides a optional auxiliary modules for elastic and knitted fabrics.
主要特點 Characteristics
1. 能將1800mm幅寬對折成雙幅再卷成橢圓形。
2. 機械速度：0-100米變頻調速。
3. 最大卷板尺寸：H300*W400（mm）
4. 自動對折裝置：由兩套自動對邊裝置控制布邊，一套用于矯正對折后兩布邊之整齊，另一套用于矯正前之檢出器位置。
5. 自動退布裝置：機械式壓鈕，布卷即自動脫落。
6. 高精度電子計數器：米、碼可以切換，計數準確、可靠。
7. 外形尺寸（長*寬*高）（cm）：320*290*240）
1. Working width: provides double fabric of 1800mm width to half and wind up in flat roll. (Extra size subject to negotiation).
2. Speed: 0-100yards/min, step-less adjustment.
3. Maximum flat roll: 300mm(height)*400mm(width)
4. Edge control device: by two sets of photo-electric edge control device. One for aligning the two selvages of folded fabric, the other for guiding the position of the former device’s feeler.
5. Auto take-up device: provides to release finished rolls automatically after rolling.
6. High-precision electrically countless machine, it can cut meter and yard, precise and reliable in calculation.
7. External form size: 320cm(length)*290cm(width)*240cm(height).
